GENERAL
WI2 series loT circuit breaker is a multi-function intelligent switch that integrates the functions of electricity metering,overload,short circuit,over and under voltage,leakage,over-temperature protection,remote opening and closing,timing,network communication and so on.It can be widely used in smart power management places such as commerce,agriculture,schools,hospitals,hotels,entertainment places,stations, cultural relics protection units,urban street lamp management andl control,and can also be widely used in energy consumption management in industrial and mining enterprises,office buildings and other places.
SPECIFICATIONS
Conforming to standards | GB10963.1 |
Instantaneous trip type | Type C(other types,can be customized) |
Rated current | 16A、20A、25A、32A、40A、50A、63A、80A、100A |
Short-circuit breaking capacity | ≥6KA |
Short circuit protection | When the line is short-circuited,the circuit breaker is powered off for 0.01s |
Overvoltage protection | When the line is over or under voltage,the circuit breaker will be cut off after 3S(can be set) Over/under voltage setting demand setting percentage value |
Overload delay protection | According to the rated current of the circuit breaker,it meets the requirements of GB10963.1 standard |
Timing control | Can be set according to demand |
| View | Through the mobile phone APP.you can view the voltage,switch on and off status |
Support Voice Control | Work with Amazon Alexa/Google Assistance/IFTTT |
Manual automatic integrated control | The mobile phone APP can be automatically controlled,and can also be controlled by the push rod(handle): |
communication method | Wireless WIFI |
